● IP 53
● Drop
- MIL-STD 810G 516.6 Procedure IV, 26 drops from 3 feet height onto plywood over concrete
● Vibration
- MIL-STD 810G 514.6 AnnexC Cat.4, Fig 514.6C-1
- ASTM 4169-08 Truck Trasport, 11.5.2 Random test,Assurance Level II   无风扇工控机尽在南京研维

● Temperature
- Operating: 0℃~ 50℃
- Storage: -33℃~ 71℃
● Humidity
- Operating 5% ~ 95%

● Genuine Windows 7 Professional

● Intel Ivy Bridge Intel® Core™ i7-3520M (35W)
● Intel Ivy Bridge Intel® Core™ i5-3360M/3320M (35W) 来自南京研维QQ：2499809788

● Mobile Intel® QM77 Express Chipset

● 4/8/16 GB DDRIII SODIMM

● 2.5" SATA HDD / Optional mSATA SSD

● Intel® HD Graphics

● 14.0" HD(1366x768) TFT LCD with
● Resistive Touch Panel
● Optional 500 nits Sunglight Readable Display
● Support Stealth Mode or optional Night Vision Mode

● Intel High Definition Audio
● 1.5KHz Speaker x 1 / 90db
● Microphone x 2 for Mic. Array

● 1.3 Mega-pixel Web-cam 南京研维信息技术有限公司

● Giga LAN with optional second Giga LAN
● Intel® Centrino® Wireless-N 6235 (802.11 a/b/g/n)
● Bluetooth 4.0
● Optional Gobi 3000 WWAN+GPS or LTE

● Optional Smart Card Reader
● Computrace® Ready
● Intel ®vPro
● TPM 1.2
● Fingerprint Scanner
● Kensington Lock

● One PCMCIA Type II
● One SD card reader slot
● One Smart Card Reader or Express 54

● Two USB2.0
● Two USB3.0
● One headphone
● One microphone jack
● One RJ-45
● DC-In
● One 19 pin HDMI type A connector
● One 15 pin D-sub VGA port
● One 9 pin D-sub serial port
● Docking connector

● Standard battery pack 9-cell 7800 mAh / 6~7Hrs
● Optional secondary battery pack 6-cell 5200 nAh
● Hot-Swappable battery
● Total battery life : 9.5~11 hrs with two packs

● 110V - 240V; 90W

● 342 mm (L) x 245 mm (W) x 47 mm (H)
● 3.4 Kg ( with 2.5" SATA HDD + 9-cell battery)
